Product Description
The LEVITON W5325-T0W Decora WR/TR 15A Duplex Receptacle is a 15 amp, 125 volt duplex outlet. Constructed with UV stabilized thermoplastic and extra corrosion protection to withstand exposure to the elements. It features Quickwire push-in and side wiring for easy installation and a shutter mechanism to block access to contacts.
- Weather and Tamper-Resistant
- Quickwire push-in and side wiring for easy installation
- Shutter mechanism blocks access to the contacts
Product Highlights
This Decora duplex receptacle is ideal for outdoor residential and commercial areas, including patios, decks, and near pools and hot tubs.
Product Information
Standard Information
-
Brand: LEVITON
-
Manufacturer Part Number: W5325-T0W
-
Country of Origin: United States
Technical Specifications
-
Catalog Number: W5325-T0W
-
Manufacturer: Leviton
-
Brand: Leviton
-
Country of Origin: United States
-
Made in USA: Yes
-
UPC: 078477937785
-
GTIN: 00078477937785
-
Manufacturer Name: Leviton
-
Energy Star Flag: No
-
UNSPSC: 39121400
-
Feature8: Shutter mechanism inside the receptacle blocks access to the contacts unless a two-prong plug is inserted, helping ensure hairpins, keys, etc., will be locked out
-
Standards: C22.2 No. 42: File 152105, Class 6233-01
-
Number of Wires: 3
-
Number of Poles: 2
-
Mounting: Strap
-
Item Name: Duplex Receptacle Outlet
-
Grounding: Grounding
-
Conductor Size: 12-14 AWG
-
Amperage Rating: 15 Amp
-
Sub Brand: Decora
-
Type: Weather And Tamper-Resistant
-
Voltage Rating: 125 Volt
-
NEMA Outlet/Inlet: NEMA 5-15R
-
Series: W5325
-
NEMA Rating: 5-15R
-
Standards/Approvals: File E13399 UL 498|C22.2 No. 42 File 152105|Class 6233-01|NOM Certified
-
Termination: Quickwire Push-In & Side
-
Torque Range: 14 - 18 in.-lbs
-
CSA: C22.2 No. 42: File 152105; Class 6233-01
-
NOM: NOM Certified
-
UL 498: File E13399
-
Amperage: 15 A
-
Wire: 3
-
Device Type: Decora Receptacle
-
Feature: Weather and Tamper-Resistant
-
Weather Resistant: Yes
-
Number of Outlets: 2
-
Installation Type: Wall
-
Tamper Resistant: Yes
-
Weather Resistance: Yes
-
Blade Type: Straight
-
Grade: Residential/Commercial
-
Material: Thermoplastic
-
Mount Type: Flush
-
NEMA Configuration: 5-15R
-
Number of Pieces: 1
-
Package Quantity: 1
-
Receptacle Type: Side Wired
-
Recommended Environment: Commercial
-
USB Connection: No USB Connection
-
Voltage: 125 V
-
WiFi Capability: None
-
Wire Size: #14 AWG - #10 AWG
-
Wiring Configuration: Side
-
Certifications & Standards: CSA Certified, NEMA Rated, UL Listed
-
GSA Approved: None
-
Made in the USA: None
-
TAA/BAA Compliant: None
-
UL Listed: None
-
HazMat: Hazardous
-
Amps: 15
