Leviton UPPLC-KIT Singlemode Pigtail Kit 900UM Cable 3 M

Product Description

The Leviton UPPLC-KIT is a singlemode pigtail kit that includes twelve color-coded pigtails with LC UPC connectors. Each pigtail is long enough at three meters to facilitate easy installation and splicing. This kit is ideal for use in a fiber cabling system where mechanical and fusion splicing are required.

• Includes twelve individual color-coded pigtails
• Each pigtail supports LC UPC connectors
• Three meters in length for appropriate reach

Product Highlights

This pigtail kit is designed for fiber optic installations, making it a suitable choice for both mechanical and fusion splicing.

Product Information

Standard Information

• Brand: Leviton
• MPN: UPPLC-KIT

Technical Specifications

• Fiber Count: 12
• Connector Type: LC/UPC
• Length: 3 m
• Color Family: Aqua/Black/Blue/Brown/Green/Orange/Purple/Red/Rose/Slate/White/Yellow
• Application: Supports fusion or mechanical splicing for fiber cabling systems
• Temperature Rating: -40 to 75 degrees Celsius
• Attenuation Rating: 0.25 dB Max Insertion Loss, >50 dB Return Loss
• Standards/Approvals: ANSI/TIA-598-D-1, ANSI/TIA-568.3-D, TIA-598-A, GR 1435
