Leviton TSF01-10I Preset Toggle Slide Quiet 3 Speed Fan Control 1.5 Amp

Product Description

The LEVITON TSF01-10I is a preset toggle slide quiet 3-speed fan control, compatible with single pole/3-way circuits, operating at 1.5 Amp-120VAC. Designed for residential use, it features quiet operation. It combines a toggle ON/OFF switch with a contemporary slender slide bar for fan speed selection.

• Quiet Operation
• 3-Speed Fan Control
• Single Pole/3-Way Compatibility

Product Highlights

This fan speed control is ideal for residential settings, libraries, and home offices, ensuring minimal noise distraction.

Product Information

Standard Information

• Brand: LEVITON
• Manufacturer Part Number: TSF01-10I
• Country of Origin: China

Technical Specifications

• Catalog Number: TSF01-10I
• Manufacturer: Leviton
• Brand: Leviton
• Country of Origin: China
• Made in USA: No
• Application: Residential
• Special Features: Quiet
• Standard: cCSAus
• UPC: 078477771716
• GTIN: 00078477771716
• Item Type: Fan Speed Control
• Voltage Rating: 120 VAC
• Amperage Rating: 1.5 A
• Environmental Conditions: 20 to 90% Non-Condensing Relative Humidity
• Mounting: Threaded
• Operational Mode: 3-Speed/Quiet
• Standards/Approvals: cCSAus Certified|NOM Approved|UL 1917|CSA C22.2
• Temperature Rating: 0 to 55 deg C
• Type: 1-Pole 3-Way Electro-Mechanical Preset Toggle Slide
• Action: Toggle Switch for ON/OFF, slide bar for fan speed level control
• Preset: Yes
• Load Type: Fan
• Wallplate: Order Separately
• Protection: Radio/TV Filter
• Style Name: Toggle Slide
• Load Rating: 1.5 Amp
• Switch Type: Single-Pole & 3-Way
• Available Colors: White, Ivory, Light Almond
• Operating Voltage: 120 Volts (AC)
• Maximum Current: 1.5 Amps
• Smart Home Compatibility: Not Smart Home Compatible
• Compatible Devices: Fans
• Control Type: Manual
• Number of Positions: 3
• Wattage: 180 watts
• Circuit Type: 3-way
• Poles: 1-Pole
• Amperage: 1.5 A
