Leviton T5638-20W 18W USB Type A/Type-C Wall Outlet Charger 15A (Single) T5638-20W

Product Description

Leviton T5638-20W combines an integrated 18W USB Type-A and Type-C charging module with a 15A, 125V tamper-resistant Decora duplex receptacle for standard wall installation. The device delivers a combined 18W (3.6A) USB output and uses a built-in smart chip to optimize charging (not Power Delivery). It supports grounding and accepts back and side wiring with #14-#12 AWG copper or #10-#12 copper-clad conductors and a 14-18 in-lb torque range.

• Combined USB output: 18W total (3.6A) across Type-A and Type-C ports; built-in smart chip (not Power Delivery)
• AC receptacle: 15A, 125V tamper-resistant Decora duplex (NEMA 5-15R) with grounding
• Wiring: back and side termination; accepts #14-#12 AWG copper or #10-#12 copper-clad; torque 14-18 in-lbs

Product Highlights

Integrated 18W USB A/C charging with grounded tamper-resistant 15A outlet; back and side wiring; cCSAus listed.

Product Information

Standard Information

• Brand: LEVITON
• Manufacturer Part Number: T5638-20W
• Country of Origin: Mexico

Technical Specifications

• Brand: Leviton
• Manufacturer Part Number: T5638-20W
• UPC: 078477020128
• Device Type: Decora tamper-resistant duplex receptacle with integrated USB charger
• NEMA Configuration: 5-15R
• Input Voltage: 125 V
• Amperage (AC): 15 A
• USB Power (Total): 18 W
• USB Output Current (Combined): 3.6 A
• USB Types: Type A and Type C
• Charging Control: Built-in smart chip (does not provide Power Delivery)
• Grounding: Grounding provided
• Termination / Wiring: Back and side wire terminals accept #14-#12 AWG copper or #10-#12 copper-clad wires
• Torque Range: 14-18 in-lbs
• Number of Poles: 2
• Wire Conductors: 3
• USB Durability: Ports tested to withstand over 10,000 insertions
• Certifications: cCSAus Listed
• Tamper-Resistant: Yes
