Leviton MT563-SW 20-Amp, 125-Volt, Narrow Body Duplex Receptacle, Fed Spec Commercial Grade

Product Description

The Leviton MT563-SW is a 20-amp, 125-volt narrow body duplex receptacle designed for commercial use. This fed specification commercial-grade receptacle features tamper resistance and self-grounding capabilities. It is suitable for a wide range of applications in environments requiring durable and safe electrical connections. The modular terminal design allows for simple installation.

• 20 amp rating and 125 volt compatibility
• Self-grounding and tamper-resistant features
• Designed for reliable performance in commercial settings

Product Highlights

The Leviton MT563-SW offers a combination of safety and efficiency with its durable thermoplastic construction and modular connection system.

Product Information

Standard Information

• Manufacturer: Leviton
• Catalog Number: MT563-SW

Technical Specifications

• Amperage Rating: 20 A
• Voltage Rating: 125 VAC
• Number of Poles: 2
• Number of Wires: 3
• NEMA Rating: NEMA 5-20R
• Material: Thermoplastic
• Color: White
• Mounting: Wall
• Temperature Rating: -40 to +60 degrees C
• Dimensions: 46 inches H x 1.53 inches W x 1.36 inches D
