Leviton Mfg Co S11-05801-KIS Single Outlet 125V 10-pack

Product Description

The LEVITON MFG CO S11-05801-KIS is a commercial specification grade single outlet designed for demanding electrical installations where reliability and wiring flexibility are required. Built with a shallow profile to maximize wiring room inside the box, it features side-wired connections with large-head terminal screws that accept up to No. 10 copper wire. Double-wire power contacts deliver strong conductivity and plug retention. Captive mounting screws keep hardware in place during installation. Rated at 125 volts, this outlet carries a limited 10-year warranty and is UL listed. Licensed electricians install this device in commercial and light-industrial applications.

This outlet is suited for commercial construction, tenant improvement projects, and specification-grade electrical work where standard residential devices do not meet the required grade. The washer-type break-off plaster ears allow for clean flush mounting in plaster or drywall finishes. Break-off fins enable 2-circuit conversion when wiring configuration requires splitting the duplex outlets to separate circuits. Each package contains 10 units, making this well-suited for rough-in and finish electrical work across multiple boxes in a single project.

Key Features

• Commercial specification grade construction for high-demand installations
• Shallow design maximizes wiring room inside standard electrical boxes
• Large-head terminal screws accept up to No. 10 copper wire for side-wiring
• Double-wire power contacts for improved conductivity and plug retention
• Break-off fins allow 2-circuit conversion without additional hardware
• Captive mounting screws prevent hardware loss during installation
• UL listed with a limited 10-year warranty

Compatibility

Designed as a specification-grade single outlet for commercial electrical installations requiring 125-volt single receptacle devices in standard wall box configurations.

Installation Notes

Installation should be performed by a licensed electrician in accordance with NFPA 70 (National Electrical Code) requirements. De-energize the circuit at the breaker panel and verify absence of voltage with a meter before wiring. Use the side-wire terminal screws for connection and ensure conductor seating is secure under the large-head screws. When converting to 2-circuit operation, break the connecting fin fully before completing the wiring.
