Leviton Mfg Co R20-LB220-0TR 20A 2-pole Circuit Breaker

Product Description

The LEVITON MFG CO R20-LB220-0TR is a 20-amp, 2-pole standard branch circuit breaker rated for 120/240 volt residential and light commercial panel applications. It uses thermal magnetic trip technology to provide both overload and short-circuit protection. The thermal element responds to sustained overcurrent conditions, while the magnetic element trips instantly under short-circuit fault current. The plug-on design speeds up installation in compatible load centers. Licensed electricians install this breaker as a branch circuit protection device in accordance with NEC requirements.

This breaker is suited for 2-pole branch circuit applications in residential and light commercial load centers. Typical uses include 240-volt dedicated circuits for appliances such as electric dryers, ranges, water heaters, HVAC equipment, and similar double-pole loads. It is packaged in a quantity of 5 units per package, making it practical for multi-circuit panel builds or service upgrades where several breakers are required at once.

Key Features

• 20-amp, 2-pole configuration for 120/240 volt branch circuit protection
• Thermal magnetic trip technology provides overload and short-circuit protection
• Plug-on installation design for fast, tool-free seating in compatible load centers
• Packaged 5 units per package for multi-circuit panel applications
• Standard branch circuit breaker profile for straightforward replacement or new installation

Compatibility

Designed as an OEM-style plug-on replacement or new-install standard branch circuit breaker for compatible residential and light commercial load centers accepting 2-pole plug-on breakers. No specific panel model compatibility was stated in the product data.

Installation Notes

Installation must be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and all applicable local codes. Always shut off main power to the load center and verify the panel is de-energized with a non-contact voltage tester before handling any breaker. Do not install a 2-pole breaker in a panel that does not support the plug-on mounting style specified for this unit. Ensure the circuit wire gauge is rated to match the 20-amp overcurrent protection provided by this breaker.
