Leviton M8200-GY Hospital Grade Duplex Receptacle 15A

Product Description

The LEVITON M8200-GY is a hospital-grade, straight-blade duplex receptacle rated at 15 amps and 125 volts AC with a NEMA 5-15R configuration. Built for flush-mount installation in single-phase wiring systems, this self-grounding outlet is constructed from impact-resistant and tamper-resistant thermoplastic and carries a gray finish. It accepts three-wire, two-pole connections via wire lead termination. Licensed electricians install this receptacle in healthcare facilities, commercial buildings, and any application where hospital-grade reliability and tamper resistance are required by code.

The M8200-GY is suited for flush-mount electrical box installations in hospital patient care areas, outpatient clinics, and other commercial environments where hospital-grade outlets are specified. Its self-grounding design eliminates the need for a separate grounding clip during installation, reducing labor time. The tamper-resistant and impact-resistant construction makes it appropriate for high-traffic areas and locations subject to physical abuse.

Key Features

• Hospital-grade rating for use in patient care and commercial environments
• Self-grounding design simplifies installation without a separate grounding clip
• Tamper-resistant and impact-resistant thermoplastic body
• NEMA 5-15R configuration, 15 amps at 125 volts AC, single-phase
• Flush-mount, wire-lead termination with three-wire, two-pole wiring
• Meets ANSI C-73, NEMA WD-1, NEMA WD-6, and cULus listing requirements

Compatibility

Designed as an OEM-style hospital-grade replacement duplex receptacle for standard single-gang flush-mount electrical boxes wired to NEMA 5-15R specifications.

Installation Notes

Installation must be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and all applicable local codes. De-energize and lock out the circuit at the panel before removing the existing device or making any wire connections. Flush-mount receptacles require a compatible single-gang electrical box properly secured in the wall. Hospital-grade devices installed in patient care areas must comply with NFPA 99 health care facility electrical requirements.
