Product Description
The Leviton LP322-LPD is a main lug load center designed for indoor use with a voltage rating of one hundred twenty to two hundred forty volts and a maximum amperage of two hundred twenty-five. It includes thirty spaces for circuits and provides a robust enclosure. The load center features convenient mounting, offering flexibility in installation and efficient power distribution.
- Features a NEMA one rated enclosure for indoor applications.
- Utilizes a galvanized steel housing for durability and strength.
- Allows easy modifications between main lug and main breaker configurations.
Product Highlights
This load center is ideal for residential and light commercial applications where circuit management is essential.
Product Information
Standard Information
-
Manufacturer: Leviton
-
MPN: LP322-LPD
Technical Specifications
-
Amperage Rating: 225 A
-
Voltage Rating: 120/240 VAC
-
Number of Spaces: 30
-
Dimensions: 37 inches H x 14.25 inches W x 4 inches D
-
Enclosure Type: NEMA 1
-
Weight: 28 lbs
-
Ground Connection: 4 AWG - 2/0 AWG Cu/Al
-
Supply Connection: 3 AWG - 300 MCM Cu/Al
-
Short Circuit Rating: 10 kA
