LEVITON Leviton GFNT1-PW SmartlockPro Slim GFCI Receptacle 15 Amp (1 Pack)
LEVITON Leviton GFNT1-PW SmartlockPro Slim GFCI Receptacle 15 Amp (1 Pack)

Leviton GFNT1-PW SmartlockPro Slim GFCI Receptacle 15 Amp (1 Pack)

Brand: LEVITON
SKU: GFNT1-PW
Availability: In Stock

Ships same day if ordered by 12 pm
$32.38
$32.38
HAVE A QUESTION?

Our team is ready to help!

215-326-9845
  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Description

Product Description

Leviton GFNT1-PW is a 15 Amp SmartlockPro Slim GFCI receptacle that provides continuous ground-fault protection with automatic self-testing. It is rated 125 VAC with a 20 Amp feed-through and Class A 5 mA trip sensitivity. The device features back-and-side wiring, a status indicator for power and protection, a reduced depth design for shallow boxes, and a screwless wallplate with subplate and self-grounding clip.

  • Continuous ground-fault protection with automatic self-test and status indicator for power, protection, and line/load reversal
  • 15 A, 125 VAC rating with 20 A feed-through and Class A (5 mA ± 1 mA) trip sensitivity
  • Back and side wiring with external back wire clamps, reduced depth for shallow boxes, and screwless wallplate included

Product Highlights

SmartlockPro self-test GFCI; 15 A, 125 VAC; 20 A feed-through; back & side wiring; NEMA 5-15R

Product Information

Standard Information

  • Brand: LEVITON
  • Manufacturer Part Number: GFNT1-PW
  • Country of Origin: China
Technical Specifications
Brand
Leviton
Manufacturer Part Number
GFNT1-PW
Model
GFNT1-PW
Type
GFCI receptacle
Amperage
15 A
Input Voltage
125 VAC
Feed-through Rating
20 A
Trip Level
Class A, 5 mA ± 1 mA
Horsepower Rating
1 HP at rated voltage
Dielectric Voltage Withstand
Withstands 1250 VAC per UL 943 and CSA-C22.2 No. 144.1-06
Short Circuit Current Rating
10 kA
Temperature Rise
Max 30°C after 100 cycles overload at 150% rated current
Operating Temperature
-35°C to +66°C
Body Material
Polycarbonate
Face Material
Thermoplastic
Clamps
Brass
Grounding Screw
Plated steel
Line Contacts
Brass double-wipe, .031 thick
Terminal Screws
Plated steel
Yoke
Zinc-plated steel
Terminal Accommodation
14-10 AWG
Terminal Identification
Brass-Hot, Green-Ground, Silver-Neutral
Termination
Back and Side
Torque Range
14-18 in.-lbs
Poles
2
Wire
3
Grounding
Self-Grounding (standard brass self-grounding clip)
Grade
Residential/Commercial Specification Grade
Tamper Resistant
No
NEMA
5-15R
Standards and Certifications
NEMA WD6, NEMA WD1, ANSI C-73, CSA-C22.2 No. 144.1-06 (File LR-57811), UL498, Fed Spec WC-596
Accessories Included
Screwless wallplate with subplate and self-grounding clip
Product ID Note
Ratings are permanently marked on device
Notes
Reduced depth design for easier installation; improved immunity to high-frequency nuisance tripping
UPC
0078477714065
