Product Description
The Leviton CS120-2W is a commercial specification grade switch designed for reliability and top performance in commercial settings. This toggle single-pole AC quiet switch is rated at 20 Amp and 120/277 Volt. Ideal for municipal facilities, government buildings, and healthcare facilities. It features side wiring for easy installation.
- AC Quiet Switch
- Commercial Grade
- Side wired connection accommodates terminal of size 14 - 12 AWG
Product Highlights
The Leviton CS120-2W is suitable for commercial applications and meets UL, CSA, NEMA, ANSI, and NOM standards.
Product Information
Standard Information
-
Brand: LEVITON
-
Manufacturer Part Number: CS120-2W
-
Country of Origin: United States
Technical Specifications
-
UNSPSC Code: 39122211
-
Type: Toggle
-
Current Rating: 20 Ampere
-
Voltage Rating: 120/277 VAC
-
Power Rating: 1 HP at 120 V, 2 HP at 240 V
-
Operation Type: Single Pole
-
Material: Thermoplastic
-
Wiring: Side
-
Size: 46 H x 1.31 W x 0.92 D
-
Wall Plate Included: No
-
Application: Commercial, Specification Grade
-
Approval: UL 20, CSA C22.2, NOM 057
-
Operating Temperature: -40°C to 65°C
-
Grounding Type: Self Grounding
-
Strap Material: Steel
-
Contact Material: Silver-Cadmium
-
Wire Size: 14 to 12 AWG (Side)
-
Voltage: 120/277 Volt
-
Amperage: 20-Amps
-
Poles: 1-Pole
-
Switch Grade: Commercial/Specification Grade
-
Actuator Material: Polycarbonate
-
Body Material: Thermoplastic
-
Dimensions: 4.06-Inch x 1.31-Inch x 0.92-Inch
-
Terminal Size: 14 - 12-AWG
-
Dielectric Strength: 1500-Volts
-
Temperature Rating: -40 to 65 deg C
-
Contact Material Thickness: 0.031-Inch thick silver cadmium
-
Wattage: 800 W
-
VA Power: 1000 VA
-
Contact Configuration: SP Contact
-
Pole: 1
-
Actuator: Toggle
-
Enclosure: NEMA WD-1/WD-6
-
Mounting: Surface
-
Terminal: Side Wire
-
Number Of Poles: Single-Pole
-
Country of Origin: US
-
Environmental Conditions: Dry Location
-
Amperage Rating: 20 A
-
Standards/Approvals: ANSI C73|CSA C22.2 No. 111 File No. 152105|NOM 057|Federal Specification WS896E File No. E7458|UL 20|UL94 V-2 Flammability Rating
-
Terminal Type: Side Wire
-
Mfg Standards/Approvals: ANSI (C-73), CSA C22.2 No. 111 (File 152105) Certified, NEMA (WD-1 and WD-6), NOM Certified (057), RoHS Compliant, UL Fed Spec WS896E (File E7458), UL 20 Listed
-
Environment: -40 to 120 deg C
-
Package Weight: 0.13 L
-
Terminal ID: Brass-Hot, Green-Ground, Silver-Neutral
-
Termination: Side Wire
-
Cover Material: Nylon
-
Max. Amperage: 16 Amp
-
Terminal Screws: Steel 8-32
-
Flammability: Rated V-2 per UL94
-
Screw Terminal Torque: 14-18 in-lbs
-
Toggle Material: Polycarbonate
-
Warranty Length: 10 yr
-
Connection Type: Side Wired
-
Grade: Commercial
-
Action: SP
-
Torque: 12 lb-in
-
Mounting Type: Box
-
TC Connection: Side Wired
-
Temperature Rise: 30 degrees C
-
Flamability Class: Rated V-2 Per UL94
-
HP Rating: 1HP-120V 2HP-240V-277V
-
Max Current: 16 A
-
Wiring Syle: Side Wired
-
Contact Type: Single Pole
-
Made in the USA: Yes
-
Terminal Gauge Max: 10 AWG ga
-
Terminal Gauge Min: 14 AWG ga
-
Switch Type: 1-Pole
-
Description/Special Features: Quiet Switch
-
Switch Style: Toggle
-
Base Material: PBT
-
Terminal Accom.: 14-12 AWG
-
Rated HP: 1
-
Voltage AC: 120 to 277
-
UL Standard: UL 20
-
CSA C22.2 No. 111: File #152105
-
UL Fed Spec WS896E: File #E7458
-
Application Environment: Commercial
-
Country of Origin (subject to change): United States
-
Item: Wall Switch
-
NEMA: WD-1 & WD-6
-
ANSI: C-73
-
Function: Single-Pole
-
Wiring Method: Side
-
Device Type: Toggle Switch
-
Catalog Number: CS120-2W
-
Manufacturer: Leviton
-
Brand: Leviton
-
Made in USA: Yes
-
Item Type: Toggle Switch
-
Width: 1.31
-
Width UOM: Inch
-
Height: 46
-
Height UOM: Inch
-
Depth: .92
-
Depth UOM: Inch
-
Cross Reference Products: CS20AC1W
-
Manufacturer Item Status: Active
-
Brand Name: Leviton
-
GTIN: 00078477815748
-
Alternative Part Number: 7334077
-
Amperage Rating UOM: A
-
Voltage Rating UOM: VAC
-
Warranty: 10 year Limited
-
IGCC: 5200
-
Vendor: 78477
-
Family group: WIRING DEVICES
-
WES Product code: 2734562740
-
Market Class: C28
