Leviton AGTR1 Gfci Receptacle Commercial 5-15R Manual Reset

Product Description

The LEVITON AGTR1 is a commercial-grade GFCI receptacle designed to provide ground-fault circuit-interrupter protection at the point of use. Rated for a NEMA 5-15R configuration, it accepts standard 15-amp, 125-volt plugs and delivers the personnel protection required by NEC code in wet, damp, and other specified locations. The manual reset type requires deliberate action to restore power after a fault trip, giving installers and inspectors a clear indication that the device has operated. Electricians install this receptacle in commercial and residential applications wherever code mandates GFCI protection.

The AGTR1 is suited for commercial installations including bathrooms, kitchens, garages, outdoor locations, and anywhere the NEC requires GFCI protection on 15-amp branch circuits. It supports both back-wired and side-wired termination methods, giving electricians flexibility during rough-in and retrofit work. With a single-phase, 3-wire, 2-pole configuration, it fits standard duplex receptacle rough openings and works with common single-gang wallplates. This unit ships individually, making it practical for single-outlet replacements or small-batch service calls.

Key Features

• Commercial-grade construction for demanding installation environments
• NEMA 5-15R configuration accepts standard 15-amp, 125-volt plugs
• Manual reset type provides clear fault-trip indication
• Dual wiring method: back-wire and side-wire terminations supported
• Single-phase, 2-pole, 3-wire design fits standard single-gang rough openings
• CSA Certified for verified safety compliance

Compatibility

Designed as an OEM-style replacement for commercial-grade GFCI receptacles in standard single-gang electrical boxes on 15-amp, 125-volt branch circuits.

Installation Notes

Installation must be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and all applicable local codes. De-energize the branch circuit at the panel and verify the absence of voltage with a meter before beginning any wiring work. Both back-wire and side-wire termination points are available on this device — do not use both methods simultaneously on the same terminal. After installation, test the GFCI function using the built-in test and reset buttons before restoring the circuit to service.
