Leviton 8410 20-Amp, 125/250V Single Receptacle, Straight Blade, Commercial Grade, Grounding

Product Description

The Leviton 8410 is a 20-Amp, 125/250V single receptacle with a straight blade, designed for commercial use and grounding. This heavy-duty specification grade receptacle is manufactured to withstand demanding environments. It is suitable for hotels, schools, hospitals, and commercial office buildings.

• 20-Amp
• 125/250V
• Commercial Grade

Product Highlights

This single receptacle is ideal for commercial applications requiring a durable and reliable power connection.

Product Information

Standard Information

• Brand: LEVITON
• Manufacturer Part Number: 8410
• Country of Origin: Mexico

Technical Specifications

• Voltage: 250 Volts
• Amperage: 20 Amps
• Material: Nylon
• Certification: UL
• Batteries Included?: No
• Batteries Required?: No
• Included Components: 8410
• NEMA: 14-20R
• Type: Single Receptacle
• Grade: Commercial
• Standard: UL Listed
• Grounding: Grounding
• Sub Brand: LOCKING DEVICES
• Wire Size: 14-10 AWG
• Wire Count: 4
• Applications: Commercial
• Body Material: Phenolic
• Mounting Type: Box
• TC Connection: Back Wired;Side Wired
• Connection Type: Back and Side Wired
• Number of Poles: 3 Pole
• Number of Wires: 4 Wire
• Termination Type: Back Wire,Side Wire
• Volts: 125/250 VAC
• Poles: 3
• Wires: 4
• Voltage Rating: 125/250 V
• Amperage Rating: 20 A
• Terminal Type: Back/Side Wire
• Application: Commercial Applications
• IGCC: 4536
• Mounting: Box
• Family group: WIRING DEVICES
• Manufacturer: LEVITON
• Pole/Wire: 3P4W
• NEMA Configuration: 14-20R
• Ground Type: Grounding
• Device Configuration: Single Receptacle
• Number of Phases: 1 Phase
• Wiring Method: Back and Side Wired
• Screw Terminal Torque: 14-18 in-lbs
• Brand Name: Leviton
• Brand Part Number: 8410
• ARRA Compliant: C
• Buy American Compliant: C
• Catalog Number: 8410
• Connection: Back Wired;Side Wired
• Country of Origin: MX
• EU RoHS Indicator: C
• Strap Material: Steel
