Leviton 5304M-1S5 Surge Outlet Strip 4-outlet 125V Hospital

Product Description

The LEVITON 5304M-1S5 is a hospital-grade surge-protected power outlet strip rated for 125 volts AC and 15 amps. The unit provides four NEMA 5-20 outlets along a 1-foot steel strip body and ships with a 15-foot power cord, giving technicians and facilities staff meaningful reach from the wall outlet to the point of use. Manual trip reset means the overcurrent protection can be restored on-site without replacing any components. UL 60601-1 certification confirms compliance with electrical safety standards for medical electrical equipment environments. Wall or surface mounting keeps the strip off floors and work surfaces in demanding clinical settings.

This outlet strip is intended for hospital and medical facility installations where UL 60601-1-listed power distribution is required. It is well suited for patient care areas, equipment rooms, and procedure spaces where surge protection and a fixed mounting position are necessary. The 5-20 NEMA configuration supports equipment with 5-20P plugs, which are common on medical and laboratory devices. Licensed electricians typically handle the installation in healthcare facilities to meet local codes and facility requirements.

Key Features

• Four NEMA 5-20 outlets on a 1-foot strip body
• Surge protection with manual trip reset
• UL 60601-1 certified for medical electrical equipment environments
• 15-foot power cord for extended reach from the supply outlet
• Steel construction, white finish, wall and surface mount capable
• 125V AC, 15A rating suitable for standard branch circuit connections

Compatibility

Designed for wall or surface mount installation in hospital and medical facility environments requiring UL 60601-1 listed surge-protected outlet strips with NEMA 5-20 configuration.

Installation Notes

Installation in medical facilities should be performed by a licensed electrician in accordance with NFPA 99 and applicable local electrical codes. Power down the branch circuit at the panel before mounting or connecting the strip. Verify that the supply receptacle is a NEMA 5-20R rated for 15 amps at 125 volts before plugging in. Do not bypass or override the manual reset mechanism if the strip trips during use.
