Leviton 2310 Locking Receptacle 20 Amp 125 Volt Industrial Grade

Product Description

Leviton 2310 is a locking receptacle that operates at 20 Amps and 125 Volts. It serves industrial applications and is built to withstand severe conditions. This receptacle features a grounding connection and is designed for flush mounting. It is constructed from durable materials to ensure reliability in demanding environments.

• UL 94 V-O flammability rating for enhanced safety.
• Accommodates wire sizes from fourteen to eight AWG.
• Easy identification with a color-coded voltage rating on the face.

Product Highlights

This receptacle is ideal for commercial applications, including motors, shop vacs, and generators.

Product Information

Standard Information

• Manufacturer: Leviton
• MPN: 2310

Technical Specifications

• Amperage Rating: 20 A
• Voltage Rating: 125 V
• Number of Wires: 3
• Number of Poles: 2
• Material: PBT
• Dimensions: 3.63 in H x 1.69 in W x 1.31 in D
• NEMA Rating: L5-20R
• Temperature Rating: -40 to +60 degrees C
• Dielectric Strength: 2000 V
