Leviton 16P22-UW Nema 3R Female Protective Cap

Product Description

The LEVITON 16P22-UW is a single-pole protective cap rated NEMA 3R for use with male plugs in outdoor or weather-exposed electrical installations. This female cap covers energized male plug contacts when the plug is not in use, protecting against rain, sleet, and external ice formation in accordance with NEMA 3R environmental standards. Finished in white, it installs without tools and is handled by licensed electricians during panel, outlet, or cord-and-plug circuit maintenance. At 0.25 pounds, it is a lightweight, single-unit component stocked for individual replacement or service-call use.

This protective cap is suited for residential and light commercial electrical applications where a male plug or connector is left disconnected in an outdoor or damp-location environment. NEMA 3R-rated enclosures and fittings are commonly specified on rooftop HVAC disconnects, exterior receptacle circuits, and temporary power installations where weather protection is required between uses. The cap keeps exposed contacts clean and dry until the next connection is made.

Key Features

• NEMA 3R rating provides protection against rain, sleet, and external ice formation
• Female configuration covers and protects energized male plug contacts
• Single-pole design for straightforward single-circuit plug protection
• White finish for standard visibility in residential and commercial settings
• Lightweight construction at 0.25 pounds for easy single-hand installation

Compatibility

Designed as an OEM-style protective accessory for use with single-pole male plugs in NEMA 3R-rated outdoor or damp-location electrical installations.

Installation Notes

Installation and removal of electrical caps and connectors should be performed by a qualified electrician following applicable NEC requirements. De-energize the circuit at the breaker or disconnect before servicing any plug, cap, or connector. Do not install this cap on an energized male plug while the circuit is live. Confirm NEMA 3R compatibility with the male plug being protected before placing the cap in service.
