Leviton 16D33-UR 16 Series Single Pole Cam Type Female Detachable Plug Taper Nose, 600 Volts, Rated Up To 400 Amperes Continuous, 2/0 To 4/0

Product Description

The Leviton 16D33-UR is a single pole cam type female detachable plug designed for high-performance applications. Rated for six hundred volts and up to four hundred amperes, it is suitable for a cable range of one over zero to four over zero.

• Durable thermoplastic housing
• Double set screw connection for secure attachment
• Interoperable with competitive products

Product Highlights

This product is optimal for power distribution on construction sites, during concerts, and in television productions.

Product Information

Standard Information

• Manufacturer: Leviton
• Voltage Rating: 600 VAC

Technical Specifications

• Amperage Rating: 400 A
• Color: Red
• Wire Size: 2/0 to 4/0 AWG
• Connection Type: Double Set Screw
• Contact Material: Brass
• Dimensions: 1.72 inches Diameter x 6.85 inches Length
• Housing Material: Santoprene TPV
• Mounting Type: Threaded
• NEMA Rating: NEMA 3R
• Temperature Rating: 86 degrees F
