Leviton 16D22-UW 300A 600V Single Pole Cam Plug

Product Description

The LEVITON 16D22-UW is a single-pole male cam-style plug and connector designed for high-current electrical connections in demanding environments. Rated at 300 amps and 600 volts, it terminates wire sizes from 2 AWG to 2/0 AWG using a double set screw method that provides a secure, vibration-resistant connection. The NEMA 3R rating means the enclosure is protected against falling rain and ice formation, making this connector suitable for outdoor and covered outdoor installations. At 7.01 inches in overall length and weighing 0.7 pounds, it is a robust single-pole device installed by licensed electricians in temporary power distribution, generator connections, and portable power applications.

This connector is used in temporary power distribution assemblies, portable generator hookups, stage and event power systems, and industrial maintenance applications where quick-connect, high-amperage single-pole connections are required. The double set screw termination accommodates the full wire range from 2 AWG through 2/0 AWG, giving electricians flexibility across a range of conductor sizes in the same connector body. The white color coding helps identify polarity or phase assignments on multi-pole cam connector assemblies.

Key Features

• 300 amp, 600 volt rating for heavy-duty temporary and permanent power connections
• Double set screw termination accepts 2 AWG to 2/0 AWG conductors
• NEMA 3R rated enclosure resists rain and ice in outdoor installations
• Male single-pole cam-style connector for quick, tool-assisted mating
• Overall length of 7.01 inches with a total weight of 0.7 pounds
• Listed to UL 1691 and CSA standards for code-compliant installations

Compatibility

Designed as an OEM-style single-pole cam connector compatible with standard cam-style single-pole connector systems rated at 300 amps and 600 volts.

Installation Notes

Installation should be performed by a qualified, licensed electrician in accordance with the National Electrical Code (NEC) and any applicable local codes. De-energize and lock out the circuit before terminating or disconnecting this connector. Use the double set screw terminals with appropriately sized conductors within the rated 2 AWG to 2/0 AWG range, and confirm proper torque on set screws using a calibrated torque screwdriver per the manufacturer installation sheet. Do not exceed the 300 amp or 600 volt ratings under any operating condition.
