Product Description
The LEVITON 13353-N is a standard lamp holder designed for medium bi-pin fluorescent lamps. Rated for 660W and 600VAC, it features slide-on mounting and quick-connect connections. Ideal for commercial applications, this lampholder ensures safe and efficient lighting in various indoor spaces. It has a thermoset body and turn-type contact.
- 6-32 zinc plated nut
- Turn type contact
- 3/8 in wire strip length
- Quickwire 18 AWG solid or stranded tinned
Product Highlights
Standard fluorescent lampholder with medium base, bi-pin design, and quick-connect terminals for easy installation.
Product Information
Standard Information
-
Brand: LEVITON
-
Manufacturer Part Number: 13353-N
-
Country of Origin: Please Contact Customer Service
Technical Specifications
-
Type: Standard, Low Profile
-
Material: Thermoset
-
Lamp Type: Fluorescent Lamp
-
Lamp Wattage: 660 W
-
Mounting Type: Slide-On
-
Lamp Base Type: Medium Bi-Pin
-
Voltage Rating: 600 VAC
-
Connection Type: Quick-Connect
-
Wattage: 660 Watt
-
Base Type: Medium Base Bi-Pin
-
Terminal Type: Quickwire
-
Overall Length: 1.68 in
-
Overall Width: 1.25 in
-
Overall Depth: 0.72 in
-
Standards: UL File E5833 Listed, CSA File LR-5863 Certified, NOM 057 Certified
-
Body Material: Thermoset
-
Contact Material: Copper-Alloy
-
Contact Type: Turn Type
-
Nut: 6-32 Zinc-Plated
-
Panel Thickness: 18-20 Ga. Panel
-
Screw: 6-32 X 3/8 Zinc-Plated
-
Termination: Quickwire 18AWG Solid or Str. Tinned
-
Wire Strip Length: 3/8 Inch
-
Style Name: Low Profile
-
Application: Commercial Applications
-
Bulb Type: Fluorescent Lamp
-
Lampholder Base: Medium (G13) Base
-
Lampholder Type: Linear Fluorescent
-
Operator Type: Turn Type
-
Rated Voltage: 600V
-
Lampholder Watts: 660W
-
Wire Gauge: 18 AWG
-
Plating: Zinc Plated
-
CSA: LR-5863
-
Base: Medium
-
Standard: CSA,NOM,UL
-
Sub Brand: FLUORESCENT LAMPHOLDERS
-
Light Type: Fluorescent
-
Applications: For Commercial use
-
Mounting: Slide-On
-
Terminal Connection: Quick-Connect 18 AWG Solid/Stranded Tinned
-
Maximum Load Capacity: 660 Watt
-
UNSPSC: 39110000
-
Manufacturer Part Number: 13353-N
