Leviton 1254 Fourplex Receptacle 15A 125V Nema 5-15R Brown

Product Description

The LEVITON 1254 is a specification-grade fourplex straight blade receptacle rated at 15 amps and 125 volts AC, configured to NEMA 5-15R. The fourplex design provides four outlet positions in a single device, reducing the need for multi-gang boxes in high-density wiring applications. The self-grounding feature automatically establishes the ground connection through the mounting yoke when installed in a properly grounded metal box, eliminating the need for a separate ground pigtail. The nylon body provides chemical, corrosion, and impact resistance suited to commercial and light industrial environments. Licensed electricians are the primary installers of this device.

The LEVITON 1254 is used in commercial, institutional, and light industrial applications where multiple outlet positions are required at a single location. Flush mount installation in standard electrical boxes makes it a common choice for workbenches, equipment rooms, server rooms, and office buildouts. The specification grade rating indicates it meets the durability and performance standards typically required on commercial construction projects and facilities maintenance work.

Key Features

• Fourplex configuration provides four NEMA 5-15R outlets in a single device
• Specification grade construction for commercial and industrial-duty installations
• Self-grounding yoke eliminates separate ground pigtail in grounded metal boxes
• Nylon body is chemical-resistant, corrosion-resistant, and impact-resistant
• Back wiring method for straightforward termination
• Single-phase, 2-pole, 3-wire configuration for standard 125V circuits

Compatibility

Designed as an OEM-style specification-grade replacement or new-installation receptacle for standard flush-mount electrical boxes wired to NEMA 5-15R, 15-amp, 125-volt single-phase branch circuits.

Installation Notes

Installation must be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and applicable local codes. Always de-energize the branch circuit at the panel and verify absence of voltage with a meter before beginning work. The self-grounding feature is only effective when the device is installed in a grounded metal box with a code-compliant equipment grounding path; verify ground continuity after installation. Do not install on circuits exceeding 15 amps or 125 volts AC.
