Leviton 1223-2 Toggle 3-Way AC Quiet Switch 20 Amp 120/277 Volt

Product Description

Leviton 1223-2 is a toggle 3-way AC quiet switch designed for heavy-duty applications. This switch supports a voltage rating of 120/277 volts and a current rating of 20 amps. Its construction includes thermoplastic material for durability and long-lasting use. This switch is self-grounding, ensuring safe operation and easy installation.

• Compatible with both back and side wiring for flexible installation
• Rated for a minimum of 50,000 operating cycles for reliability
• Complies with NEMA and ANSI standards for superior performance

Product Highlights

This toggle switch from Leviton is ideal for commercial environments and provides robust performance under varying operational conditions.

Product Information

Standard Information

• Brand: Leviton
• MPN: 1223-2

Technical Specifications

• Voltage Rating: 120/277 VAC
• Amperage Rating: 20 A
• Power Rating: 800 W, 1000 VA
• Contact Rating: 1 hp at 120 VAC, 2 hp at 240 VAC
• Operating Cycles: 50000 Cycles
• Operating Temperature: -40 to 65 deg C
• Material: Thermoplastic
• Mounting Type: Surface mount
• Enclosure: NEMA WD-1/WD-6
• Grounding: Self-grounding
• Endurance: 50000 cycles minimum
• Environmental Conditions: Rated V-2 per UL94
• Standards/Certifications: CSA C22.2 No. 111, UL Listed
