Lenox 93739RPB154775 Bandsaw Blade 15ft 8in 5-8 Tpi Bi-metal

Product Description

The LENOX 93739RPB154775 is a welded bi-metal bandsaw blade engineered for demanding metal cutting applications. It measures 15 feet 8 inches in length and 1-1/4 inches wide, with a blade thickness of 0.042 inches and a kerf width of 0.068 inches. The blade features a variable pitch tooth form in a 5 to 8 TPI range with a Vari-Raker tooth set and a positive rake angle. The cutting edge is constructed from M42 high speed steel teeth bonded to a spring steel back — a combination that delivers heat resistance and flex durability under continuous bandsaw use. Licensed HVAC and metal fabrication shops, pipefitters, and industrial maintenance technicians rely on this blade format for high-volume stock cutting.

This blade is built for horizontal and vertical bandsaw machines used in commercial and industrial settings. The variable pitch design reduces vibration and harmonic resonance during cuts, making it effective on a wide range of metal stock cross-sections including solid bar, structural shapes, and tube. The RX Plus series designation places this blade in LENOX's line of production-grade bi-metal blades suited for shops running continuous cutting cycles. Installation requires a bandsaw frame sized to accept a 15 feet 8 inch blade with a 1-1/4 inch wide guide setup.

Key Features

• Bi-metal construction with M42 high speed steel teeth on a spring steel back for durability and heat resistance
• Variable pitch tooth form at 5 to 8 TPI reduces vibration and improves cut surface finish
• Vari-Raker tooth set distributes cutting load and extends blade life on varied stock profiles
• Positive rake angle promotes aggressive chip removal on metal stock
• Pre-welded loop at 15 feet 8 inches ships ready to install with no field welding required
• 0.068 inch kerf width minimizes material waste during production cutting

Compatibility

Designed as an OEM-style replacement welded bandsaw blade for industrial horizontal and vertical bandsaws accepting a 15 feet 8 inch blade loop with a 1-1/4 inch wide blade guide configuration.

Installation Notes

Installation should be performed by a qualified machinist or industrial maintenance technician familiar with bandsaw blade tensioning and tracking procedures. Disconnect and lock out power to the bandsaw before removing the existing blade or installing the new one. Set blade tension and tracking according to the bandsaw manufacturer specifications before making a test cut. Wear cut-resistant gloves when handling the coiled or uncoiled blade — the teeth are sharp along the full working length.
