Lenox 93732RPB123660 Welded Bandsaw Blade 12 Ft Bi-metal

Product Description

The LENOX 93732RPB123660 is a welded bi-metal bandsaw blade engineered for demanding metal-cutting applications. Measuring 12 feet long and 1-1/4 inches wide with a 0.042-inch blade thickness, it runs on horizontal and vertical bandsaw machines commonly found in fabrication shops and mechanical service environments. The blade features M42 high speed steel teeth bonded to a spring steel back, delivering extended tooth life when cutting ferrous and non-ferrous metals. A variable pitch tooth form rated at 5 to 8 TPI reduces vibration and harmonic noise across a range of workpiece cross-sections. This blade is part of the LENOX RX Plus series and is sold as a single welded unit ready to mount.

This blade is suited for production cutting environments where variable material sizes and profiles are common. The variable pitch design helps maintain consistent feed rates on both thin-walled and solid stock. The Vari-Raker tooth set and positive rake angle promote efficient chip evacuation, reducing heat buildup at the cut. Fabricators, pipefitters, and general metalworking shops will find this blade appropriate for structural steel, tubing, angle iron, and similar materials. It is not designed for contour cutting applications.

Key Features

• Bi-metal construction with M42 high speed steel teeth bonded to a spring steel back for extended blade life
• Variable pitch tooth form at 5 to 8 TPI reduces vibration and harmonics during the cut
• Vari-Raker tooth set with positive rake angle for efficient chip removal
• Kerf width of 0.0680 inches for precise, low-waste cuts
• 12-foot welded loop, 1-1/4 inches wide, ready to install with no additional joining required
• Part of the LENOX RX Plus series, designed for high-production bandsaw use

Compatibility

Designed as an OEM-style replacement or service blade for horizontal and vertical bandsaws that accept a 12-foot by 1-1/4-inch blade. Verify your machine's blade length, width, and thickness specifications before installation.

Installation Notes

Bandsaw blade replacement should be performed by qualified personnel familiar with the specific machine model. Disconnect and lock out power to the saw before removing the old blade or installing a new one. Wear cut-resistant gloves when handling the coiled or uncoiled blade. Confirm blade tension, tracking, and guide settings according to the bandsaw manufacturer's specifications before resuming operation.
