Lenox 91023NEB103175 Welded Bandsaw Blade 10 Tpi

Product Description

The LENOX 91023NEB103175 is a welded bandsaw blade designed for contour cutting applications in metal fabrication, woodworking, and general-purpose cutting operations. This blade measures 10 feet 5 inches in length and 3/4 inch in width, with a blade thickness of 0.032 inches. It runs a constant pitch pattern at 10 teeth per inch (TPI) with a raker tooth set and straight tooth form, delivering consistent, controlled cuts across a range of materials. The carbon steel construction in both the blade body and tooth material provides durability for sustained cutting cycles. A hard back type adds rigidity and helps the blade track cleanly on the bandsaw's guide system. Licensed HVAC techs, machinists, pipefitters, and fabricators rely on blades like this for repeatable contour and straight-line cuts in production and service environments.

This blade is suited for use on bandsaw machines that accept a blade length of 10 feet 5 inches and a 3/4-inch blade width. The 10 TPI constant pitch configuration is appropriate for cutting medium-thickness stock where a balance of cut speed and surface finish is required. The raker set pattern clears chips efficiently, making it practical for both dry cutting and lightly lubricated operations. It is packaged and sold as a single blade unit.

Key Features

• Welded construction — 10 feet 5 inches blade length, ready to mount
• 3/4-inch blade width with 0.032-inch thickness for stable tracking
• 10 TPI constant pitch for consistent chip load and cut quality
• Raker tooth set with straight tooth form for efficient chip clearance
• Carbon steel blade body and tooth material for general-purpose durability
• Hard back type adds rigidity and reduces blade flex during cuts
• Contour cutting capable for curved and irregular workpiece profiles

Compatibility

Designed as an OEM-style replacement or direct-fit welded bandsaw blade for bandsaws configured to accept a 10 feet 5 inch blade length and 3/4-inch blade width.

Installation Notes

Bandsaw blade replacement should be performed by a qualified operator with the machine fully powered down and locked out per OSHA lockout/tagout procedures before blade removal or installation. Verify wheel diameter, blade length, and blade width compatibility with the bandsaw manufacturer specifications before mounting. Wear cut-resistant gloves when handling the blade, as tooth edges are sharp. After installation, confirm blade tension and tracking alignment before resuming operation.
