Product Description
The LENOX 3001010L Speed Slot Bi-Metal Hole Saw with 4/5 variable pitch TPI features a thread size of 1/2"-20. The blade has a staircase design for easy plug removal, enhanced tooth geometry, a thin kerf design, and an advanced coating for enhanced cutting process efficiency. Designed for use with wood and metal.
- Features a staircase design for easy plug removal
- Enhanced tooth geometry and a thin kerf design
- Advanced coating for enhanced cutting process efficiency
Product Highlights
The LENOX Speed Slot hole saw is virtually indestructible, shatter-resistant, cuts faster, and lasts longer than other hole saws. Ideal for cutting holes in metal, stainless steel, wood, and plastic.
Product Information
Standard Information
-
Brand: LENOX
-
Manufacturer Part Number: 3001010L
-
Country of Origin: US
Technical Specifications
-
Material: High Speed Steel
-
Blade Size: 5/8"
-
Blade Type: Bi-Metal
-
Trade Name: Speed Slot®
-
Arbor/Shank: 1/2" - 20"
-
Cutting Depth: 1.83"
-
Saw Blade Type: Hole Saw
-
Teeth Per Inch: 4/5 Variable Pitch
-
MPN: 3001010L
-
Applicable Materials: Stainless and Mild Steel, Cast Iron, Copper, Brass, Aluminum, Plastic, Wood and Composition Board
-
Body Material: Bi-Metal
-
Cutting Diam [Nom]: 5/8 in
-
Cutting Edge Material: Bi-Metal
-
Shank Type: Hex
-
Type: Hole Saw Blade
-
Used With: Arbored Hole Saws
-
Saw Dia.: 5/8 in
-
Tooth Material: Bi-Metal
-
Diameter: 5/8 Inch
-
Sub Brand: Speed Slot®
-
Thickness: 0.05 in
-
Shank Size: 3/8 in Hex
-
Applications: General Purpose
-
Material Type: Bi-Metal
-
Technology Type: Bi-metal
-
ECCN: EAR99
-
Hole Diameter: 5/8 in.
-
Use Arbor: 5L Snap-Back, 1L, 4L or 5L Standard
-
Arbor Size: 1/2 in
-
Drill Size: 1/4 in
-
Overall Length: 3-1/4 in
-
Cutting Edge Style: Toothed
-
Diameter MM: 15.9
-
Uses arbor number: 1L, 4L or 5L
-
Tool Material: High Speed Steel
-
Size Type: Fractional
-
Model #: 3001010L
-
Saw Diameter: 5/8"
-
Maximum Cutting Depth: 1-3/4"
-
Flute Material: High Speed Steel
-
Saw Style: Tuff Tooth Series
-
Application: Hole cutting in metal, stainless steel, non-ferrous metals, plastics, composites & wood
-
First Choice For:: Stainless Steel (ISO M)
-
Hardness: 58 to 60 RC
-
Tooth Pattern: Var-tooth
-
Workpiece Material Range: Steel (ISO P), Stainless Steel (ISO M), Non-Ferrous (ISO N), Cast Iron (ISO K), Plastics
-
Unit Size: 1
-
Pieces Per Unit: 1/EA
-
Product Brand: Lenox
-
Product Name: 5/8" Lenox Bi-Metal Hole Saws 1-Pack, 3001010L
-
Cordless: No
