Lenox 1792752 Welded Bandsaw Blade 2-3 Tpi Bi-metal

Product Description

The LENOX 1792752 is a welded bi-metal bandsaw blade engineered for demanding metal-cutting applications. The blade measures 138 inches long, 1 inch wide, and 0.035 inches thick, with a variable 2 to 3 TPI pitch pattern designed to reduce vibration and improve chip evacuation across a range of material thicknesses. The M42 high speed steel tooth tips are joined to a spring steel back, delivering heat resistance and flex durability in continuous cutting cycles. This is a Classic Pro series blade intended for professional use on metal-cutting band saws in fabrication, machine shops, and production cutting environments.

The 1792752 is suited for structural and production metal sawing where varying cross-sections or mixed material batches are common. The variable Vari-Raker tooth set and positive rake angle support aggressive feed rates without sacrificing surface finish. Compatible with metal-cutting band saw machines that accept a 138-inch blade. Applicable material types include alloy steel, carbon steel, stainless steel, structural steel, tool steel, mold steel, bearing steel, aluminum, and other non-ferrous metals.

Key Features

• Bi-metal construction: M42 high speed steel teeth bonded to a spring steel back for durability and flex resistance
• Variable 2 to 3 TPI pitch with Vari-Raker tooth set reduces vibration and improves cut quality
• Positive rake angle supports efficient chip removal and aggressive feed rates
• Toothed, milled, variable cutting edge style for consistent performance across material cross-sections
• Rated for a broad material range including stainless steel, tool steel, aluminum, and non-ferrous metals
• Welded construction provides a continuous loop ready for direct installation

Compatibility

Designed for metal-cutting band saw machines that accept a 138-inch welded loop blade with a 1-inch blade width. Verify blade tension specifications and wheel diameter requirements on the host machine before installation.

Installation Notes

Blade installation should be performed by a qualified operator familiar with band saw equipment. Power down and lock out the saw before removing the old blade or installing a new one. Wear cut-resistant gloves when handling the blade, as tooth edges remain sharp during handling. Follow the band saw manufacturer guidelines for blade tension, tracking adjustment, and guide bearing clearance before resuming cuts.
