Lenox 1602D2C1464 Band Saw Blade Coil 1/4 in 100 Ft

Product Description

The LENOX 1602D2C1464 is a bi-metal band saw blade coil stock designed for continuous-use cutting applications in fabrication, metalworking, and general trade shop environments. The coil measures 100 feet in length and 0.25 inches wide, with a blade thickness of 0.025 inches. The cutting edge uses a variable pitch pattern of 10-14 TPI with a modified raker tooth set and high speed steel teeth, which reduces vibration and harmonic chatter during cuts. The flexible back construction allows the blade to be cut and welded to length for a wide range of band saw frames. Licensed tradespeople and shop technicians are the primary installers.

This coil stock is suited for contour cutting and general-purpose band sawing in both residential shop and light commercial fabrication settings. The variable 10-14 TPI pitch handles a range of material thicknesses and cross-sections without requiring blade changes between jobs. The bi-metal construction pairs a flexible alloy steel back with high speed steel teeth, extending edge life compared to carbon-steel alternatives. The 100-foot coil provides enough material for multiple blade welds, making it practical for shops that maintain an in-house blade welder.

Key Features

• Bi-metal construction: flexible alloy steel back with high speed steel tooth edge for extended service life
• Variable pitch 10-14 TPI reduces vibration and improves cut finish across varied material thicknesses
• Modified raker tooth set promotes efficient chip clearance and consistent feed rate
• Toothed cutting edge with contour-cutting capability for curved and irregular profiles
• Flexible back design accommodates cutting and re-welding to custom lengths
• 100-foot coil provides material for multiple blade welds from a single stock roll

Compatibility

Designed as a coil stock replacement for band saws that accept 0.25-inch wide blades welded to a custom running length. Verify your band saw wheel diameter, gullet depth, and blade guide specifications before cutting and welding.

Installation Notes

Cutting and welding band saw blade coil stock requires a dedicated blade welder and grinder; this work is typically performed by a qualified shop technician or tool-and-die professional. Disengage and lock out power to the band saw before installing or tensioning any blade. Follow the band saw manufacturer's tension and tracking specifications when mounting the finished blade. Do not exceed the minimum blade radius recommended for the 0.25-inch width, as over-flexing will fatigue the weld joint.
