Lennox 11F49 Terminal Block 300V 15A 3-place Ac

Product Description

The LENNOX 11F49 is a 3-place terminal block designed for use in air conditioning equipment. It provides a secure, organized connection point for field and load-side wiring within the unit. Rated at 300 volts and 15 amps, this terminal block is built to handle the electrical demands of residential air conditioner wiring compartments. Measuring 1.81 inches in length, it fits into space-constrained control areas without modification. Licensed HVAC technicians install this component when servicing or replacing damaged wiring terminations during equipment repair or refurbishment.

This terminal block is suited for residential air conditioning systems where a compact, multi-conductor termination point is required inside the electrical compartment. It is commonly installed during service calls involving wiring damage, corrosion, or terminal failure. Its 3-place configuration supports organized, code-compliant connections in systems where multiple conductors must terminate at a single accessible location.

Key Features

• 3-place terminal layout for organized multi-conductor wiring terminations
• Rated 300 volts and 15 amps for standard residential AC electrical loads
• Compact 1.81-inch length fits space-constrained equipment wiring compartments
• OEM-style replacement for air conditioner terminal block applications

Compatibility

Designed as an OEM-style replacement terminal block for use in LENNOX air conditioning equipment requiring a 3-place, 300V, 15A terminal block.

Installation Notes

This component is installed by licensed HVAC technicians. Disconnect and lock out all electrical power to the unit before beginning any wiring work. Verify that conductor wire gauges are appropriate for the 15-amp rating before terminating. Work should comply with applicable NEC requirements for equipment wiring and electrical enclosures.

Technical Specifications

• Voltage Rating: 300 volts
• Amperage Rating: 15 amps
• Number of Places: 3
• Length: 1.81 inches
• Weight: 0.1 pounds
• Application: Air Conditioner

Standard Information

• Brand: LENNOX
• Manufacturer Part Number: 11F49
