Legris 31090817 90 Male Elbow 3/8 Male BSPT

Product Description

Legris 31090817 is a 90-degree male elbow fitting designed for connecting semi-rigid plastic tubing in pneumatic systems. This fitting is engineered to create tight, leak-free connections with ease. The body of the fitting is made from glass-filled nylon, while the threaded components are constructed from nickel-plated brass. Buna-nitrile elastomer seals further enhance reliability.

• Compatible with 5/16 inch or 8 mm O.D. tubing.
• Working temperature range from -4 °F to 175 °F.
• Vacuum rating up to 28 inches of mercury.

Product Highlights

This fitting allows for simple and tool-free assembly. The patented stainless steel gripping ring secures the tubing firmly, making disconnection equally straightforward with a built-in plastic release button.

Product Information

Standard Information

• Brand: Legris
• MPN: 31090817

Technical Specifications

• End Types: Tubing & BSPT
• Fitting Angle: 90°
• Size Type: Metric Sizes
• Origin: Plastic Push to Connect Fittings
• Thread Type: BSPT
• No. of Ends: 2
• Tube O.D.: 5/16 inches, 8.000 mm
• Thread Size: 3/8
• Hex Size: 17 mm
• End Size: 5/16 or 8 mm Tube (female)
• Height: 18.000 mm
• Material: Nickel-Plated Brass
• Body Material: Nickel-Plated Brass
• Fitting Description: 90° Male Elbow
• Weight: 0.04 LB
• EAN or UPC: 820099220819
