Legris 0205 10 00 Hollow Hex Plug 1/8 in Mbspt Brass

Product Description

The LEGRIS 0205 10 00 is a hollow hex plug designed for industrial pipe systems requiring a reliable threaded closure with MBSPT male thread configuration. Machined from brass, this plug seats into a female-threaded port and provides a rated working pressure of 1000 psi, with a burst-tested pressure rating of 3626 psi. The hex drive allows standard wrench installation without special tooling. Its compact profile — 0.38 inches wide and 0.31 inches tall — makes it suitable for tight port locations on manifolds, valve bodies, and instrument connections. Plumbers, pipefitters, and industrial maintenance technicians install this type of fitting as part of pressure system commissioning or port sealing during system modifications.

This hollow hex plug is intended for use in pressurized fluid or gas systems where an unused port must be sealed using a male MBSPT threaded connection. The MBSPT thread type is a British Standard Parallel Pipe Taper male thread commonly found on European and internationally sourced pneumatic and hydraulic components. Suitable for operating temperatures ranging from -40 degrees F to 302 degrees F, this plug performs across a wide range of ambient and process conditions, including refrigeration-adjacent systems, compressed air lines, and general industrial fluid circuits.

Key Features

• 1/8 inch male MBSPT thread for direct engagement with compatible female-threaded ports
• Brass construction provides corrosion resistance and reliable sealing in fluid and gas service
• 1000 psi maximum working pressure rated for demanding industrial applications
• Pressure rating of 3626 psi provides substantial safety margin above working pressure
• Operating temperature range of -40 degrees F to 302 degrees F suits a wide range of service environments
• Compact dimensions of 0.38 inches wide by 0.31 inches tall fit restricted port access areas

Compatibility

Designed for use in pipe systems with 1/8 inch female MBSPT-threaded ports on pneumatic, hydraulic, and fluid distribution components. Confirm thread type and port specification before installation, as MBSPT threads are not interchangeable with NPT or BSPP thread forms without appropriate adapters.

Installation Notes

Installation should be performed by a qualified pipefitter or industrial maintenance technician familiar with the applicable thread standard. De-pressurize and isolate the system completely before removing or installing any threaded plug. Apply an appropriate thread sealant or PTFE tape compatible with the process fluid and pressure rating. Do not overtighten; use a calibrated torque wrench and follow the fitting manufacturer guidance for brass fittings in the applicable thread class.
