Legrand TR-8301RED 20A 125V Hospital Grade Receptacle Red

Product Description

The LEGRAND TR-8301RED is a 20-amp, 125-volt hospital grade duplex receptacle designed for demanding healthcare and critical-care electrical installations. Rated at 20A and 125V, it carries the green dot hospital grade designation, indicating it meets the elevated construction and retention-force standards required for patient care areas. The tamper-resistant (TR) feature incorporates internal shutters that block foreign object insertion unless both slots are engaged simultaneously. Licensed electricians install this device during new construction or renovation of healthcare, laboratory, and similarly regulated environments.

This receptacle is suited for hospital patient care vicinity circuits, surgical suites, outpatient clinics, and any facility where NEC Article 517 compliance is required. The red color body provides immediate visual identification of hospital grade or dedicated isolated-ground circuits, making it easy to distinguish critical circuits during inspections and service calls. It is also applicable in laboratory and industrial settings where a high-retention, tamper-resistant 20A receptacle is specified.

Key Features

• 20A, 125V rating meets hospital grade current and voltage requirements
• Tamper-resistant shutters prevent accidental or unauthorized object insertion
• Red color body provides instant visual identification of critical or dedicated circuits
• Hospital grade construction meets elevated contact retention and durability standards
• NEMA 5-20R configuration accepts standard 20A and 15A plugs

Compatibility

Designed as an OEM-style hospital grade duplex receptacle for 20-amp branch circuits in healthcare and critical-facility electrical systems. No specific compatible model numbers were provided in the product data.

Installation Notes

Installation should be performed by a licensed electrician in accordance with NEC Article 517 and applicable local codes governing patient care areas. De-energize the branch circuit at the panel and verify absence of voltage with a meter before beginning work. Do not install this device on circuits exceeding 125 volts or 20 amps. Confirm wall plate and enclosure compatibility with the device yoke dimensions prior to installation.

Technical Specifications

• Amperage: 20A
• Voltage: 125V
• Grade: Hospital Grade
• Tamper Resistant: Yes
• Color: Red
• UPC: 78500703087

Standard Information

• Brand: LEGRAND
• Manufacturer Part Number: TR-8301RED
