Legrand L1230R Pass & Seymour Turnlok Single Receptacle 480V

Product Description

The LEGRAND L1230R Pass & Seymour Turnlok single receptacle is a 3-wire, 30 amp, 3-phase, 480V receptacle. Features a compact, impact-resistant nylon face and body ultrasonically welded for strength. It is suitable for commercial applications.

• Compact, impact-resistant nylon face and body are ultrasonically welded together for unrivaled strength.
• Face color coding by voltage facilitates locating and mating of proper devices.
• One piece, high-grade brass contacts offer excellent conductivity and heat-rise resistance.

Product Highlights

The LEGRAND L1230R is a durable and reliable receptacle for commercial use, featuring robust construction and easy installation.

Product Information

Standard Information

• Brand: LEGRAND
• Manufacturer Part Number: L1230R
• Country of Origin: Mexico

Technical Specifications

• NEMA: L12-30R
• Type: Single Receptacles
• Brand: Legrand
• Voltage: 480 Volt
• Amperage: 30 Amp
• Material: Thermoplastic
• Sub Brand: Pass & Seymour
• Wire Size: 10 AWG
• Applications: Commercial
• Certifications: CULUS
• Conductor Size: 18-10 AWG
• Number of Poles: 3 Pole
• Number of Wires: 3 Wire
• Number of Phases: 3 Phase
• Amperage Rating: 30 A
• Horsepower: 10 hp
• Manufacturer Part Number: L1230R
• NEMA Rating: NEMA L12-30R
• Standards/Approvals: UL 498
• Temperature Rating: -40 to 75 deg C
• Product Line: Pass & Seymour
• Country Of Origin: Mexico
• Brass Mounting Strap: Impact Resistant
• Wall Plate Included: No
• Number of Receptacles: 1
• Outlet Type: Locking
• UPC Number: 785007123050
• cULus ListingNumber: 140596
• cULus Listed: Yes
• Product Environmental Profile: Yes
• Connection Location: Back and Side
• Wire Connection Type: Screw Terminals
• Indoor/Outdoor: Indoor
• NEMA Configuration Code: L12-30R
• Phase: Three
• GTiN: 00785007123050
• Product UPC: 78500712305
• Depth: 1.28 Inch
• Height: 2.42 Inch
• Width: 1.61 in
