Legrand IG5362-RED 20A Duplex Receptacle

Product Description

The LEGRAND IG5362-RED is a 20-amp isolated ground duplex receptacle designed for commercial and industrial electrical installations where sensitive electronic equipment requires a clean, interference-free ground path. The isolated ground configuration separates the equipment grounding conductor from the general grounding system, reducing electrical noise that can disrupt computers, audio/visual systems, medical equipment, and other noise-sensitive loads. This receptacle is finished in red, the standard color convention used to identify isolated ground circuits on a panel. It is installed by licensed electricians in commercial offices, data centers, healthcare facilities, and similar environments.

This receptacle is suited for 20-amp, 125-volt branch circuits where an isolated ground is specified by the engineer or required by the application. The red color provides a quick visual indicator at the face, making it easy to identify protected circuits during service and troubleshooting. Typical installations include dedicated computer circuits, workstation drops, and sensitive instrumentation panels in both new construction and retrofit projects.

Key Features

• 20-amp isolated ground duplex receptacle reduces electrical noise on sensitive equipment circuits
• Red finish serves as a standard visual identifier for isolated ground circuits
• Duplex configuration provides two outlets from a single gang box installation
• Designed for commercial and industrial branch circuit applications

Compatibility

Designed as an OEM-style replacement or new-installation isolated ground duplex receptacle for standard single-gang electrical boxes on 20-amp, 125-volt branch circuits.

Installation Notes

Installation must be performed by a licensed electrician in accordance with the National Electrical Code (NEC). De-energize the branch circuit at the panel and verify absence of voltage with a meter before wiring. The isolated ground conductor must be run separately from the equipment grounding conductor back to the panel as required by NEC Article 250. Do not connect the isolated ground terminal to the standard grounding bus at intermediate junction points.

Technical Specifications

• Amperage: 20 amps
• Configuration: Duplex
• Ground Type: Isolated Ground
• Color: Red
• Weight: 0.25 pounds
• UPC: 78500704536

Standard Information

• Brand: LEGRAND
• Manufacturer Part Number: IG5362-RED
