Legend Valve M300 1 1/4 Brass Gate Valve Fip

Product Description

The LEGEND VALVE M300 1 1/4 is a brass gate valve designed for full-flow shutoff and isolation service in water supply and distribution piping systems. Gate valves use a rising-stem wedge mechanism to open or close flow completely, making them well-suited for service lines where the valve is operated infrequently and left in a fully open or fully closed position. The M300 1 1/4 features female iron pipe (FIP) threaded connections on both ends and is machined from brass for corrosion resistance in potable water and general plumbing applications. This valve is typically installed by licensed plumbers in residential and light commercial water systems.

The M300 1 1/4 is suited for residential and light commercial plumbing systems where a reliable, full-bore gate valve is needed at a 1.25-inch pipe connection point. Common installation scenarios include main line shutoffs, branch isolation, and service entry points where low pressure drop across the valve is a priority. The FIP thread pattern connects directly to standard male-threaded pipe fittings and valves without adapters.

Key Features

• Brass body construction provides corrosion resistance for water service applications
• Female iron pipe (FIP) threaded connections on both ends for standard pipe fitment
• Gate valve design delivers full-bore flow with minimal restriction when fully open
• Compact and lightweight at 0.47 pounds for easy handling and installation in tight spaces

Compatibility

Designed as an OEM-style replacement or new-installation gate valve for 1.25-inch FIP-threaded residential and light commercial water supply piping systems.

Installation Notes

Installation should be performed by a licensed plumber in accordance with applicable local plumbing codes and the IPC. Shut off the water supply and relieve system pressure before removing any existing valve or fitting. Use thread sealant tape or pipe compound rated for potable water on all threaded connections. Gate valves should not be used for throttling or flow regulation service, as partial operation accelerates internal wear.

Technical Specifications

• Connection Type: Female Iron Pipe (FIP) threaded, both ends
• Pipe Size: 1.25 inches
• Body Material: Brass
• Weight: 0.47 pounds
• UPC Code: 611918007106

Standard Information

• Brand: LEGEND VALVE
• Manufacturer Part Number: M300 1 1/4
