Legend Valve LEGE-404-009 90 Degree SS304 Elbow 2.5 in Fnpt

Product Description

The LEGEND VALVE LEGE-404-009 is a 90-degree elbow fitting machined from 304 stainless steel, designed for use in plumbing and piping systems that require corrosion-resistant connections. With a 2.5-inch female NPT inlet and a 2.5-inch female NPT outlet, this fitting allows a right-angle directional change in a threaded pipe run. It carries a maximum working pressure of 290 psi at temperatures ranging from -4 to 100 degrees F, making it suitable for demanding service conditions. Licensed plumbers and pipefitters are the typical installers. The 304 stainless steel alloy is naturally lead free, which supports compliance in potable water and food-service piping applications.

This elbow is suited for residential and commercial piping installations where a 90-degree change of direction is needed in a 2.5-inch threaded line. Common applications include water supply systems, industrial fluid lines, and process piping where corrosion resistance and pressure integrity are priorities. The FNPT x FNPT connection type threads directly onto male-threaded pipe ends, requiring no special tooling beyond standard pipe wrenches and thread sealant.

Key Features

• 304 stainless steel construction for corrosion resistance in wet and aggressive service environments
• 90-degree elbow geometry for right-angle directional changes in threaded pipe runs
• FNPT x FNPT connection on both ends for straightforward threaded assembly
• Maximum pressure of 290 psi at -4 to 100 degrees F, 239 psi at 212 degrees F, and 218 psi at 302 degrees F
• Naturally lead-free alloy, suitable for potable water and food-service piping where lead-free compliance is required

Compatibility

Designed as an OEM-style threaded fitting for 2.5-inch FNPT pipe systems in residential and commercial plumbing, industrial fluid handling, and process piping applications.

Installation Notes

Installation should be performed by a licensed plumber or qualified pipefitter in accordance with applicable local plumbing codes and IPC guidelines. Shut off and depressurize the pipe system fully before removing any existing fittings or threading in this elbow. Apply an appropriate pipe thread sealant or PTFE tape to the male threads being engaged, and tighten with a pipe wrench to a snug, leak-free connection. Do not overtighten, as this can crack or distort threaded fittings.

Technical Specifications

• Size: 2.5 inches
• Fitting Shape: 90 Degrees
• Material: 304 Stainless Steel
• Connection Type: FNPT x FNPT
• Max Pressure (at -4 to 100 degrees F): 290 psi
• Max Pressure (at 212 degrees F): 239 psi
• Max Pressure (at 302 degrees F): 218 psi
• Lead Free: Yes, alloy naturally lead free
• Country of Origin: China

Standard Information

• Brand: LEGEND VALVE
• Manufacturer Part Number: LEGE-404-009
