Legend Valve LEGE-404-008 90 Degree Ss Elbow 2in Fnpt

Product Description

The LEGEND VALVE LEGE-404-008 is a 2-inch 90-degree stainless steel pipe elbow threaded female NPT on both ends. Machined from 304 stainless steel, the alloy is naturally lead-free with no added materials required to meet lead-free standards. This elbow is rated at 218 psi at 302 degrees F, 239 psi at 212 degrees F, and 290 psi at temperatures from -4 degrees F to 100 degrees F, making it suitable for high-temperature and high-pressure fluid handling applications. Licensed plumbers and pipefitters install this fitting in commercial and industrial piping systems where corrosion resistance and pressure integrity are critical.

This elbow is used in residential and commercial plumbing, hydronic heating, industrial process piping, and steam or hot water distribution systems where 304 stainless steel is specified for corrosion resistance. The FNPT x FNPT configuration threads directly onto standard male-threaded pipe and fittings. It is well suited for installations requiring compliance with lead-free material requirements under the Safe Drinking Water Act, particularly in potable water systems, food service, and medical facility piping.

Key Features

• 304 stainless steel construction — naturally lead-free alloy, no coatings or additives required
• Rated 290 psi at -4 degrees F to 100 degrees F for standard service conditions
• Rated 239 psi at 212 degrees F and 218 psi at 302 degrees F for elevated-temperature service
• FNPT x FNPT connections for direct threaded installation on standard NPT pipe
• 2-inch nominal pipe size fits common commercial and industrial piping configurations
• 90-degree turn geometry for directional changes in tight piping runs

Compatibility

Designed as an OEM-style threaded fitting for 2-inch NPT piping systems requiring a 90-degree directional change in stainless steel construction.

Installation Notes

Installation should be performed by a licensed plumber or pipefitter in accordance with applicable local plumbing codes and ASME B31 piping standards. Shut off and depressurize the system completely before removing or installing any threaded fittings. Apply an appropriate thread sealant or PTFE tape rated for the service temperature and pressure before threading the fitting into place. Do not over-tighten FNPT connections, as stainless steel threads can gall if excessive torque is applied without proper lubricant.

Technical Specifications

• Material: 304 Stainless Steel
• Pipe Size: 2 inches
• Connection Type: FNPT x FNPT
• Angle: 90 degrees
• Pressure Rating (Standard): 290 psi at -4 degrees F to 100 degrees F
• Pressure Rating (212 degrees F): 239 psi
• Pressure Rating (302 degrees F): 218 psi
• Lead-Free: Yes — naturally lead-free alloy
• Country of Origin: China

Standard Information

• Brand: LEGEND VALVE
• Manufacturer Part Number: LEGE-404-008
