Legend Valve 8330P-10-7 Port Ss Manifold /W Purge

Product Description

The LEGEND VALVE 8330P-10-7 Pro Manifold, from the M-8330P Series, features 7 outlets and a 1 in FNPT inlet. Constructed from stainless steel, it is designed for use in hydronic heating and cooling systems. The manifold has a pressure rating of 125 psi and a temperature rating of 230 deg F.

• Premium quality and enhanced features for the radiant professional
• Versatile and easily adaptable to a variety of mounting configurations
• Built-in visual flow gauges for quick circuit performance verification

Product Highlights

This stainless steel manifold includes EPDM O-rings and seals and built-in visual flow gauges for quick circuit performance verification.

Product Information

Standard Information

• Brand: LEGEND VALVE
• Manufacturer Part Number: 8330P-10-7

Technical Specifications

• Number of Outlets: 7
• Inlet Size: 1 in FNPT
• Pressure Rating: 125 psi
• Temperature Rating: 230 deg F
• Material: Stainless Steel
• Series: M-8330P
• Connection Type: FNPT
• Flow Rate: 2 to 16 gpm
• Header Pipe Size: 1 INCH
• Body Material: STAINLESS STEEL
• Seal Material: EPDM
• Model: M-8330P
• Type: PEX Manifold
• Trunk_Size: 1"
• Number_of_Branches: 7
• Trunk_Connection_Size: 1"
• Size: 1"
• Configuration: 7 Port Manifold
