Legend Valve 8330P-10-4 4 Port SS Manifold /W Purge

Product Description

The Legend Valve 8330P-10-4 is a four-port stainless steel manifold designed for hydronic heating and cooling systems. The manifold features a one-inch FNPT inlet and is rated for a pressure of 125 psi and temperature of 230 degrees Fahrenheit. With a length of fourteen point zero nine inches, this manifold ensures efficient fluid distribution within your system.

• Four adjustable flow outlets for versatility.
• Built-in visual flow gauges for performance verification.
• Includes EPDM O-rings for enhanced sealing.

Product Highlights

This manifold is manufactured by Legend Valve and is ideal for professionals involved in radiant heating applications. It provides reliable performance and easy installation.

Product Information

Standard Information

• Brand: Legend Valve
• MPN: 8330P-10-4

Technical Specifications

• Series: M-8330P
• Material: Stainless Steel
• Dimensions: 14.09 inches long
• Inlet Size: 1 inch FNPT
• Pressure Rating: 125 psi
• Temperature Rating: 230 degrees Fahrenheit
• Number of Outlets: 4
• Domestic/Import: Import
