Legend Valve 456-005NL Push-On Ball Valve (1 Inch x 1 Inch)

Product Description

Legend Valve 456-005NL is a 1-inch push-on full-port ball valve with a forged brass, lead-free body designed for push-fit x push-fit installations. The valve is rated to 200 psi CWP and temperatures up to 250°F, meets multiple plumbing standards, and is compatible with Model P-2200NL. It provides a full bore flow path for plumbing and tubing connections using Instaloc II push-fit ends.

• 1-inch nominal size, full port design with push-fit x push-fit (Instaloc II) end connections
• Forged brass construction, lead-free, rated to 200 psi CWP and 250°F
• Meets NSF 14, ANSI/NSF 61, ASSE 1061 and other plumbing standards; compatible with P-2200NL

Product Highlights

1" full-port, lead-free forged brass ball valve with Instaloc II push-fit connections rated 200 psi and 250°F

Product Information

Standard Information

• Brand: LEGEND VALVE
• Manufacturer Part Number: 456-005NL
• Country of Origin: China

Technical Specifications

• MPN: 456-005NL
• Brand: Legend Valve
• Model/Series: P-2200NL
• Product Type: Pipes/Valves/Fittings
• Product Sub-Type: Ball Valve
• Valve Type: Push / Push-to-Connect
• Nominal Size: 1 Inch x 1 Inch
• Connection Type: Push-Fit x Push-Fit (Instaloc II)
• Port Type: Full port
• Body Material: DZR forged brass (lead-free)
• Ball Material: Polished chrome forged brass
• Trim Material: DZR forged brass stem and PTFE seat
• Pressure Rating: 200 psi CWP
• Temperature Rating: Up to 250°F
• Applicable Standards/Certifications: NSF 14; ANSI/NSF 61; ASSE 1061; IAPMO/UPC; US Federal Public Law 111-380; UL listed
• Compatible Model: P-2200NL
• Actuator Type: Lever operated
• Inlet to Outlet Length: 4.05 in
• Top to Inlet Center: 2.13 in
• Weight (spec): Approximately 1.08 lbs
• Country of Origin: China
• UPC: 662545105819
• Restrictions: Not suitable for steam service
