Legend Valve 416-044 3/4 in 316 stainless steel street elbow 90 degree

Product Description

Legend Valve 416-044 is a 3/4 in 90 degree street elbow constructed from 316 stainless steel with female NPT x female NPT threads. The fitting is rated to 290 psi (varies by temperature) and to a maximum operating temperature of 302 Degree F and minimum of -4 Degree F. The alloy is naturally lead free and the item is restricted for conveying potable water.

• 316 stainless steel construction with female NPT x female NPT threaded connections
• Pressure ratings: 218 psi @ 302 Degree F; 239 psi @ 212 Degree F; 290 psi @ -4 Degree F to 100 Degree F
• Conforms to ISO 2604-2 and ISO 7-1/7-2; rated for -4 Degree F to 302 Degree F operating range

Product Highlights

3/4 in 90 degree 316 stainless steel street elbow, FNPT x FNPT, lead free alloy, ISO compliant

Product Information

Standard Information

• Brand: LEGEND VALVE
• Manufacturer Part Number: 416-044
• Country of Origin: China

Technical Specifications

• Manufacturer: Legend Valve
• MPN: 416-044
• Brand: Legend Valve
• Size: 3/4 in
• Type: 90 degree street elbow
• Material: 316 stainless steel
• Connection: Female NPT x Female NPT
• Thread Type: FNPT x FNPT
• Fitting Gender Side A: Female
• Fitting Gender Side B: Female
• Fitting Side A Nominal Pipe Size: 3/4 in
• Primary Product Type: Elbow
• Specific Fitting Shape: 90 degree elbow
• Max Operating Pressure: 290 psi
• Pressure Ratings: 218 psi @ 302 Degree F; 239 psi @ 212 Degree F; 290 psi @ -4 Degree F to 100 Degree F
• Max Operating Temperature: 302 Degree F
• Min Operating Temperature: -4 Degree F
• Standards: ISO 2604-2, ISO 7-1/7-2
• Lead Free: Yes (alloy naturally lead free)
• Compatible Tube Material: Stainless steel
• Country of Origin: China
• UPC: 662545099293
• Zoro Number: G1101837
