Legend Valve 116-105 Gate Valve 5 Inch Flanged Cast Iron

Product Description

The LEGEND VALVE 116-105 is a heavy-duty cast iron gate valve built for full-bore flow control in large-diameter pipeline systems. It features a non-rising stem design and a solid wedge disc that seats firmly to provide positive shutoff. The bolted bonnet construction adds mechanical integrity and serviceability under sustained operating pressure. At 132 pounds, this is a substantial industrial valve intended for professional installation by licensed plumbers, pipefitters, or mechanical contractors working on commercial or industrial systems.

This valve is suited for commercial and industrial piping applications where a 5-inch flanged connection is required. Typical installations include water distribution mains, fire suppression system headers, HVAC chilled or condenser water piping, and process water systems. The flanged end connection simplifies alignment and bolted assembly with mating pipe flanges, making it a practical choice for new construction as well as retrofit work where periodic valve removal may be required.

Key Features

• Non-rising stem design conserves vertical clearance in tight mechanical rooms or below-grade vaults
• Solid wedge disc provides reliable full shutoff with consistent seating force
• Bolted bonnet allows for field inspection and repacking without removing the valve from the line
• Cast iron body offers durability in water and low-pressure industrial service
• Flanged end connections at 125 pressure class for compatibility with standard flange bolt patterns
• 5-inch pipe size serves high-flow distribution and header applications

Compatibility

Designed as an OEM-style replacement or new-installation gate valve for 5-inch flanged piping systems operating within a 125 pressure class rating.

Installation Notes

Installation of a valve this size typically requires a licensed plumber or pipefitter and compliance with applicable mechanical and plumbing codes, including the IPC and ASME B16.1 flange standards. Isolate and depressurize the system fully before breaking any flange connections. Use proper lifting equipment when handling this valve, as its weight of 132 pounds presents a manual handling hazard. Verify flange bolt circle dimensions and gasket compatibility before final assembly.
