Legend Valve 116-104 Gate Valve 4 in Flanged Cast Iron

Product Description

The LEGEND VALVE 116-104 is a 4-inch non-rising stem gate valve built for industrial and commercial piping systems where full-bore flow control is required. The cast iron body and bolted bonnet construction make it a durable choice for water distribution, irrigation, and general service lines. The solid wedge disc provides positive shutoff across the valve seat, and the non-rising stem design keeps overall installed height compact — an important factor in tight mechanical rooms or below-grade installations. At 95 pounds, this is a heavy-duty flanged valve intended for permanent installation by licensed pipefitters or journeyman plumbers.

This valve is suited for 4-inch flanged piping systems in commercial buildings, municipal water distribution, industrial process lines, and large-scale irrigation infrastructure. The flanged end connection allows direct bolt-up to standard ANSI flanged piping, valve manifolds, or flanged pump and equipment ports. The 125 pressure class rating aligns it with standard cast iron flanged system piping common in commercial and light industrial applications. It is typically installed as a main line isolation valve where periodic full shutoff is needed without frequent cycling.

Key Features

• Non-rising stem design keeps installed height minimal in space-constrained applications
• Solid wedge disc delivers reliable full-bore shutoff with minimal turbulence in the flow path
• Bolted bonnet construction allows field repacking and maintenance without replacing the valve body
• Cast iron body rated for 125 pressure class service
• Flanged end connections for direct ANSI bolt-up to standard piping and equipment
• Heavyweight build at 95 pounds confirms robust, long-service-life construction

Compatibility

Designed as an OEM-style replacement or new-installation gate valve for 4-inch flanged cast iron piping systems rated at 125 pressure class in commercial, municipal, and industrial service.

Installation Notes

Installation should be performed by a licensed plumber or pipefitter in accordance with applicable local plumbing codes and ASME or ANSI flanged piping standards. Isolate and depressurize the line fully before installation and verify flange bolt patterns and gasket compatibility prior to bolting up. Do not use this valve for frequent throttling service — gate valves are designed for full-open or full-closed operation only. Due to the weight of this valve, use appropriate rigging or mechanical assistance when positioning it in the line.
