Legend Valve 116-102 Gate Valve 2-1/2 Inch Flanged Cast Iron

Product Description

The LEGEND VALVE 116-102 is a non-rising stem gate valve designed for full-bore shutoff service in commercial and industrial piping systems. Built with a cast iron body and bolted bonnet, this valve handles 2-1/2 inch flanged pipe connections at a 125 pressure class rating. The solid wedge disc provides tight shutoff when fully closed and minimal flow restriction when fully open. At 44 pounds, the 116-102 is a heavy-duty valve suited for permanent installation in mechanical rooms, pump stations, and distribution mains. Licensed plumbers and pipefitters are the typical installers for a valve of this type and size.

This gate valve is appropriate for water distribution, HVAC chilled or hot water mains, fire protection supply lines, and general industrial fluid service where a flanged full-port isolation valve is required. The 2-1/2 inch flanged end connection makes it compatible with standard Class 125 cast iron or ductile iron flanged piping systems. It is suited for both new construction and retrofit isolation applications where a non-rising stem configuration is preferred due to overhead clearance constraints.

Key Features

• Non-rising stem design conserves vertical clearance in confined mechanical spaces
• Cast iron body provides durability in wet, corrosive, or high-humidity environments
• Bolted bonnet construction allows field service and packing replacement without valve removal
• Solid wedge disc delivers reliable, leak-free shutoff
• Class 125 pressure rating for standard low-pressure water and fluid service
• Flanged end connections for secure, gasket-sealed pipe joining

Compatibility

Designed as an OEM-style replacement or new-installation gate valve for Class 125 flanged cast iron or ductile iron piping systems in commercial plumbing, HVAC, and industrial fluid distribution applications.

Installation Notes

Installation of this valve should be performed by a licensed plumber or pipefitter in accordance with the applicable plumbing code, including IPC and local authority requirements. Isolate and depressurize the system completely before making any flange connections, and verify gasket alignment before torquing flange bolts. The valve should be installed with the stem oriented to allow full handwheel operation and access for future packing service. Gate valves of this type are intended for fully open or fully closed service and should not be used to throttle flow.
