Legend Valve 114-632NL Angle Stop Valve Pex No Lead

Product Description

The LEGEND VALVE 114-632NL is a no-lead chrome brass angle stop valve designed for residential and light commercial plumbing applications. It features a dual-handle, quarter-turn operation for fast, reliable shutoff. The inlet connection is a 1/2 inch F1807 PEX fitting, with two 3/8 inch OD compression outlets, making it a dual-outlet configuration suited for supply line installations. Built to no-lead standards, this valve meets ANSI/NSF 61 requirements for contact with potable water. Licensed plumbers and experienced plumbing technicians are the primary installers for this type of angle stop valve.

The 114-632NL is intended for under-sink and similar angle stop applications where a PEX supply line ties into fixture supply connections. The 1/2 inch F1807 PEX inlet suits copper-crimp PEX systems commonly found in new construction and remodel work. The dual 3/8 inch OD outlets allow two fixture supply lines to connect from a single valve, reducing the need for additional fittings in tight spaces. This valve is appropriate for potable water systems in residential kitchens, bathrooms, and utility areas.

Key Features

• No-lead chrome brass construction meets potable water contact requirements
• Quarter-turn dual handle operation for quick, positive shutoff
• 1/2 inch F1807 PEX crimp inlet compatible with standard copper-crimp PEX systems
• Dual 3/8 inch OD compression outlets serve two fixture supply lines from one valve
• ANSI/NSF 61 certified for use in potable water systems

Compatibility

Designed as an OEM-style replacement or new-installation angle stop valve for 1/2 inch F1807 PEX supply systems terminating in 3/8 inch OD compression fixture connections.

Installation Notes

Installation should be performed by a licensed plumber in accordance with local plumbing codes and the International Plumbing Code (IPC). Shut off the main water supply and relieve line pressure before removing or installing any valve. The F1807 PEX inlet requires a compatible copper crimp ring and PEX crimp tool sized for 1/2 inch connections. Verify all compression fittings are seated and tightened before restoring water pressure, and inspect for leaks at both outlets after startup.

Technical Specifications

• Size: 1/2 inch x 3/8 inch x 3/8 inch
• Connection Type: F1807 PEX x OD Compression x OD Compression
• Material: No Lead Chrome Brass
• Operation: Dual Handle 1/4 Turn
• Standards: ANSI/NSF 61
• Country of Origin: China

Standard Information

• Brand: LEGEND VALVE
• Manufacturer Part Number: 114-632NL
