Legend Valve 110-105 1 T-431 Radiator Valve 1 in FNPT x MNPT

Product Description

The Legend Valve 110-105 is a radiator angle valve designed for steam applications. It features a 1-inch nominal size with a MNPT x FNPT end style. This valve works under a pressure rating of 60 psi CWP and is suitable for various heating applications. The inlet to outlet length is 2.85 inches, and the top to inlet center measures 3.61 inches when open and 2.95 inches when closed. The construction includes a cast bronze body with forged brass trim, ensuring reliability and durability.

• Nominal size: 1 inch
• Pressure rating: 60 psi CWP
• Media: Steam

Product Highlights

This valve is ideal for controlling steam flow in heating systems.

Product Information

Standard Information

• Manufacturer: Legend Valve
• Country of Origin: Import

Technical Specifications

• Actuator Type: Handle
• Body Material: Cast Bronze
• Trim Material: Forged Brass
• End Style: MNPT x FNPT
• Inlet to Outlet Length: 2.85 inches
• Pressure Rating: 60 psi CWP
• Series: T-431
• Top to Inlet Center: 3.61 inches Open x 2.95 inches Close
