Legend Valve 105-510 Bronze Y-strainer 3 Inch Fnpt

Product Description

The LEGEND VALVE 105-510 is a bronze Y-strainer designed for inline filtration of liquids in commercial and industrial piping systems. It features female NPT (FNPT) end connections on both ports and a 20-mesh stainless strainer screen that captures particulate before it reaches valves, meters, and other downstream equipment. The body is rated at 300 psi WOG (Water, Oil, Gas) and 150 psi WSP (Working Steam Pressure), making it suitable for a wide range of fluid service applications. Licensed plumbers and pipefitters install this strainer during new construction and retrofit work to protect system components from debris damage.

This strainer is intended for use in commercial and residential plumbing, hydronic heating, and process piping systems where inline straining is required. The 3-inch FNPT connections make it a direct threaded fit into standard iron pipe or compatible fittings. It is commonly installed upstream of pumps, control valves, and heat exchangers to extend component service life. The bronze body provides good corrosion resistance in water and many fluid service environments.

Key Features

• Bronze body construction for corrosion resistance in wet service applications
• FNPT end connections on both ports for standard threaded pipe installation
• 20-mesh strainer screen for effective inline particulate filtration
• 300 psi WOG pressure rating for broad fluid service compatibility
• 150 psi WSP rating suitable for steam system applications
• Meets ANSI, ASME B1.20.1, ASME B16.18, and ASTM B584 standards

Compatibility

Designed as an OEM-style threaded Y-strainer for use in 3-inch FNPT piping systems in commercial and residential plumbing, hydronic, and process fluid applications.

Installation Notes

Installation should be performed by a licensed plumber or pipefitter in accordance with applicable local plumbing codes and ASME standards. Shut off system pressure and drain the line before installing or servicing the strainer. Apply appropriate thread sealant to the FNPT connections per standard practice. Orient the strainer so the screen leg points downward or to the side to allow for easy blowdown and cleanout access.
