Legend Valve 104-473NL 1/2 inches S-400 No Lead Gate Valve

Product Description

The LEGEND VALVE 104-473NL is a 1/2" S-400 No Lead Gate Valve with a compact pattern. Constructed with a durable, all-brass body and a non-rising stem design, this valve ensures reliability. It is designed for use in potable water applications in California and Vermont. The valve has a pressure rating of 200 psi CWP and can withstand temperatures up to 200 deg F.

• Durable, all-brass body construction
• Non-rising stem design is compact and reliable
• Integral seats are precision-ground to match each disc-wedge

Product Highlights

This lead-free gate valve features a compact design and is suitable for potable water applications. It meets ANSI/ASME and IAPMO standards.

Product Information

Standard Information

• Brand: LEGEND VALVE
• Manufacturer Part Number: 104-473NL
• Country of Origin: Taiwan, Province of China

Technical Specifications

• Actuator Type: Handwheel
• Body Material: Cast Brass
• End Style: C x C
• Hand Wheel Diameter: 2.13 in
• Inlet to Outlet Length: 1.61 in
• Nominal Size: 1/2 in
• Pressure Rating: 200 psi CWP
• Series: S-400NL
• Softgoods Material: NBR Stem Packing
• Temperature Rating: 200 deg F
• Top to Inlet Center: 2.72 in
• Trim Material: Forged Brass
• Type: Compact Pattern
• Product Type: Gate Valve
• Brand: LEGEND VALVE
• Lead Free: Lead Free
• Connection: Sweat
