Legend Valve 104-467 1-1/2 T-400 Gate Valve

Product Description

The Legend Valve 104-467 is a durable 1-1/2 inch T-400 gate valve designed for reliable flow control in plumbing systems. This valve features a brass body and trim, ensuring it can withstand various applications, including oil and water media. Its handwheel actuator allows for easy operation.

• Compact pattern design for space efficiency
• 200 psi pressure rating for robust performance
• ISO 9002 certified for quality assurance

Product Highlights

This gate valve is ideal for both residential and commercial plumbing needs, offering a reliable option for non-steam applications.

Product Information

Standard Information

• Manufacturer: Legend Valve
• UPC: 662545001937

Technical Specifications

• Nominal Size: 1-1/2 in
• Actuator Type: Handwheel
• Body Material: Brass
• End Style: FNPT
• Pressure Rating: 200 psi
• Media: Oil/Water
• Inlet to Outlet Length: 2-1/4 in
• Top to Inlet Center: 4.57 in
• Hand Wheel Diameter: 2.96 in
• Softgoods Material: NBR Packing
• Trim Material: Brass
• Port Type: Conventional
• Series: T-400
• Domestic/Import: Import
