Legend Valve 104-464NL Gate Valve 3/4 Inch FNPT 200 PSI

Product Overview

The Legend Valve 104-464NL offers reliable water flow control in a compact, lead-free brass design. Ideal for both industrial and commercial plumbing applications, this valve features a non-rising stem with a handwheel operation, ensuring easy and secure usage.

• Handwheel operated for easy control
• Constructed from lead-free brass for safe water use
• Uses a non-rising stem design for efficient space use and operation consistency

Product Highlights

This gate valve's handwheel actuation and robust cast brass construction make it suitable for a wide range of applications including HVAC and water systems. It ensures a tight seal with its Buna-N rubber seal and precision-ground wedge disc.

Technical Specifications

• Material: Cast Brass Body, Forged Brass Stem
• Pressure Rating: 200 PSI CWP
• Size: 3/4 Inch FNPT x FNPT
• End to End Distance: 1.71 inches
• Actuation Type: Handwheel
• Standards: IAPMO, UPC, NSF 61G, ANSI/ASME B1.20.1, ASME B16.18
