Legend Valve 101-581NL 3/4 inches T-805 No Lead MIP x PEX

Product Description

The LEGEND VALVE 101-581NL is a lead-free ball valve from the T-805MNL series, featuring a 3/4 inch nominal size with MNPT x PEX end style. It operates at 400 psi CWP and has a full port design with a T-handle actuator. Constructed from forged brass, this valve is designed for various plumbing applications. It is approved to ANSI/NSF 61-G and ASTM F1806 standards.

• Lead-free construction ensures safe water contact.
• Full port design allows for unrestricted flow.
• T-handle actuator provides easy manual operation.

Product Highlights

This forged brass ball valve is lead-free and suitable for plumbing systems requiring MNPT x PEX connections.

Product Information

Standard Information

• Brand: LEGEND VALVE
• Manufacturer Part Number: 101-581NL
• Country of Origin: Italy

Technical Specifications

• Actuator Type: T-Handle
• Body Material: Forged Brass
• End Style: MNPT x PEX
• Nominal Size: 3/4 in
• Port Type: Full
• Pressure Rating: 400 psi CWP
• Series: T-805MNL
• Lead Free: Yes
• Product Type: PEX Ball Valve
